China Cosmetic Making Machine manufacturer

316material Emulsifying Machine

Product Details:
Place of Origin: CHINA
Brand Name: QIHANG
Certification: ISO,CE,GMP
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 28249$
Packaging Details: WOODEN CASE
Delivery Time: 3-4 WEEKS
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 89 SETS/YEAR

Detail Information

Capacity Of Mixer: 300L Material & Thickness: Inside Layer :316L(6mm) Jacket :304(6mm) Outside Layer:304(3mm)
Blender Material & Thickness: SUS316L(thickness : 8mm) Platform Material & Thickness: 304SUS
Speed Of Scraping System: 0-86 R/min Speed Of Homo System: 0-3500RPM
Voltage: 50Hz 380V±10%-15% Heating Way: Electricity Or Steam Heating (optional)
Control Cabinet: Button Or PLC Control Warranty: 1 Year
Certification: CE,ISO9001,GMP,ISO For High Shear Mixer
High Light:

Tilting vacuum emulsifying mixer

,

316 vacuum homogenizer

Product Description



Vacuum Emulsifying Mixer Capacity Tilting Vacuum Homogenizing Emulsify

316 Sight Glass Light Gel Making Machine



Product Description:

The vacuum emulsifiers produced by our company include many varieties. The homogenizing systems include upper homogenization, lower homogenization, internal and external circulating homogenization.
The mixing systems include single-way mixing, double-way mixing and helical ribbon mixing. The lifting systems include single-cylinder lifting and double-cylinder lifting. Various high quality products can be customized according to customers' requirements.



Specification of the Vacuum Emulsifier:

Main Pot
1.1 Working Volume Max Capacity: 50L, Mim Capacity: 17L Loading Coefficient 0.8
1.2 Material of the Tank Inner Layer: SUS 316L, 4MM Ra <0.8um
Jacket: 304, 3MM Insulation Media :Polyurethane
Outer Layer: SUS 304, 3mm SGS certificated
1.3 All contact part of
material
SUS 316L, Ra <0.8um
1.4 Agitator Speed 0.75KW, Speed 0-63rpm adjustable by inverter ABB motor,
Delta Converter
1.5 Homogeneous Way Top Homogenizer SUS316L

Homogeneous
coefficient
2.2KW, speed 0-3600R/M ABB motor,
Delta Converter
Processing Rotor and Stator in Wire cutting, assembled after polishing Balance process axle
1.6 Cover Material filter, Vacuum Pressure meter, Vacuum Exhaust Valve, Vacuum Port, sight glass light, Vision window, inlet, sight glass with wiper and bulb, rotary CIP heads, hopper;Vacuum water pump unit; Required GMP Type

1.7 Basic Structure Three layers, Helxi Stirrer,Top homogenizing;water cooling - heating coat, Insulation coat, Bidirection, Bottom product
discharge
No Dead space,
Sanitory Valve

1.8 Vacuum Pump Type Water ring type, 0.25KW,
1.9 Heating 9 KW Electrical Heating
191 Vacuum degree -0.09--0.02Mpa
Vacuum break Via GMP filter
1.92 sealing Adopting burgmann Machinery Seal,Japan NSK Rolling Bearing;
1.93 polishing In&outside hygiene grades, conforming GMP standard S320U



Details of the Vacuum Emulsifier:

316material Emulsifying Machine 0

Frame mixer

Dead-end stirring with sufficient mixing area and good stirring effect.

High shear homogenizer

Fast agitator: teethed type rotor and stater assembly installed on the vessel. Bottom or on the top as optional items, several interchangeable configurations ate available.

Hydraulic lifting system

Used for material discharge and cleaning. It is more convenient and safer for the operator.

Pharmaceutical grade material

High quality SUS304 & 316 material, internal and external mirror polish of homogenized tank.

  • The triple mixing adopts the imported frequency converter for speed adjustment, which can meet different technological demands.
  • The homogenizing structure made through German technology adopts the imported double-end mechanical seal effect. The maximum emulsifying rotation speed can reach 4,200rpm and the highest shearing fineness can reach 0.2-5μm.
  • The vacuum defoaming can make the materials meet the requirement of being aseptic. The vacuum material sucking is adopted, and especially for the powder materials, vacuum sucking can avoid dust.
  • The emulsifying pot lid can adopt lifting system, easy to clean and the cleaning effect is more obvious, the emulsifying pot can adopt tilt discharge.
  • The pot body is welded by imported three-layer stainless steel plate. The tank body and the pipes adopt mirror polishing, which fully conforms to GMP requirements.
  • According to technological requirements, the tank body can heat or cool the materials. The heating modes mainly include steam heating or electric heating.
  • To ensure the control of the whole machine is more stable, the electric appliances adopt imported configurations, so as to fully meet the international standards.



FAQ :

1. Q: Machine customization is accepted or not ?

A: We are machine manufacturer, Customization is a quality testing principle. so Customization is accepted to us.

2. Q: Are you trading company or factory ?

A: we are factory not trading company. We have the machine production license and exporting license .

3. Q: How we could know you are a trusted company ?

A: We welcome every customer come to our factory to see every machine production process. We could show any license for checking in china government and any exporting machine data from government for your checking.

316material Emulsifying Machine 1

It is widly used for cosmetic, pharmaceuticals, food, beverage, chemical.

316material Emulsifying Machine 2
