Movable Vacuum Mixer Homogenizer digital rotation speed customized Dimension

Product Details:
Place of Origin: China
Brand Name: Qihang
Certification: CE
Model Number: SE
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 4534$-23534$
Packaging Details: According to product
Delivery Time: 2-3 weeks
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 76 SETS/YEAR

Detail Information

Product Name: Vacuum Mixer Homogenizer Product Type: Cosmetic
Dimension: Customized Application: Laboratory
Features: Digital Rotation Speed Power: 1.5-4kw
Core Components: Engine Material: Stainless Steel 304 / SUS316L
Usage: Mixing Paste Proucts Application Scope: High Viscosity Product
High Light:

laboratory homogenizer mixer

,

high speed homogenizer

Product Description

Movable Vacuum Mixer Homogenizer digital rotation speed customized Dimension

SPECIAL MOVABLE HIGH SHEAR DISPERSING EMULSIFIER



High Shear Dispersing Emulsifier Description:

Disperse is designed for low-speed stirring, high-speed disperse, dissolving, mixing of various viscosity liquid product and powders liquid product and powders.

Technical parameter



Model



Main pot

Water pot

Oil pot

Main pot power (KW)

Water oil pot

(powerx 2)kw

Hydraulic system (kw)

Vacuum pump power (kw)

Volume(L)

Wall scraping

Homogenizer

5L

5L

_

_

0.18

1.1

_

0.75

0.55

10L

10L

8

5

0.18

1.1

0.18

0.75

0.75

20L

20L

18

10

0.37

1.5

0.18

0.75

0.75

50L

50L

40

25

0.75

4-7.5

0.75

1.5

1.5

100L

100L

80

50

1.5

4-7.5

1.1

1.5

1.5

200L

200L

170

100

2.2

7.5-11

1.5

1.5

2.2

300L

300L

250

150

2.2

7.5-11

1.5

1.5

2.2

500L

500L

420

250

4

11

2.2

1.5

2.2

1000L

1000L

820

500

5.5

15

2.2

2.2

3

WhatsAPP/Wechat:+8615626014514 Emily Chen

Product Application

high quality 50L/100L /200L/300L/500L vacuum emulsifying cream homogenizer mainly refers to the material in a vacuum state, using a high shear homogenizer to quickly and uniformly distribute one phase or multiple phases in at least one other continuous phase (aqueous phase, oil phase, powder, etc.) The strong kinetic energy makes the material in the gap between the stator and the rotor, and it can withstand hundreds of thousands of times of high-speed shearing, centrifugal crushing and impact tearing every minute, and evenly disperse the emulsification instantaneously. After high-frequency reciprocation, finally A high quality product with no bubbles and fineness is obtained.
Movable Vacuum Mixer Homogenizer digital rotation speed customized Dimension 0
Main components of the vacuum emulsifying cream homogenizer:
◆Hydraulic lifting system (one button lift, one button down)
◆Heating thermostat system (steam heating)
◆ Slow mixing function (frame type scraping bottom scraping)
◆Homogeneous emulsification function (high speed shear homogenizing head)
◆Vacuum system (vacuum degree up to -0.095MPA)


Performance and characteristics of vacuum emulsifying cream homogenizer:
◆Homogeneous mode: bottom homogenizing
◆The stirring method is: single way mixing
◆ Stirring and homogenization adopt imported frequency converter to meet the requirements of different production processes
◆Homogeneous structure of German technology, the speed can be customized, the highest cutting fineness can reach 2um-5um
◆ Vacuum defoaming to make the material meet the sterility requirements, vacuum suction (water, oil, powder) can be used.
◆The main pot lid can be lifted and lowered, easy to clean, and the pot body can be dumped and discharged.
◆Three-layer stainless steel structure of the pot body, mirror polished, fully in line with GMP requirements

Safety protection system of vacuum emulsifying cream homogenizer:
◆There is no vacuum to lift the lid.
◆The lid cannot be lifted when the mixture is opened.
◆The stirring cannot be started when the lid is raised or the lid is not covered.
◆The dump does not reset and the lid cannot rise and fall.
◆The lid does not rise to the highest point and cannot be dumped.
◆ Stirring, homogenizing overload, or automatic shutdown of grid overvoltage.
◆The main pot cooling water is automatically drained when the interlayer pressure exceeds the set pressure.
◆ There will be a buzzer alarm when the main pot beam rises and falls.
◆The electronic control system is equipped with an emergency stop button to prevent immediate stop in case of emergency.
◆ Safety signs (Chinese and English) are attached to the equipment rack and electrical box and the eye-catching operation



Movable Vacuum Mixer Homogenizer digital rotation speed customized Dimension 1



Qihang according to wishes designed to meet both the technical requirements and investment plan to match the best solution. And relying on their own understanding of the technology industry and the cosmetics industry professional self-control team, committed to the professional digital solutions to provide the best quality customer service.



PROJECT CASES:

Manage ltem: vacuum homogenizing emulsifiers, high shear liquid detergent mixers, reverse osmosis ion water devices, various water injection, liquid and ointment semi-automatic and automatic filling production lines, round and flat bottles automatic and semi-automatic labeling machines, perfume whole-set production lines, laboratory equipment, flow lines, etc.
