China Cosmetic Making Machine manufacturer

Cream Shampoo Liquid Soap Homogenizer Mixer Cosmetic Detergent Emulsifier

Product Details:
Place of Origin: China
Brand Name: Qihang
Certification: CE
Model Number: WES
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: According to product
Delivery Time: 2-3 weeks
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 56SETS/YEAR

Detail Information

Product Name: Cream Cosmetic Making Machine Advantages: Wear Resistant , Durable
Mixer Type: Mixer Homogenizer Product Type: Cosmetic
Voltage: 220V/380V 50HZ Automatic Grade: Automatic
Mixing Speed: 0-63 R/min Or Custom Condition: New
High Light:

Liquid Soap Homogenizer Mixer


Shampoo Homogenizer Mixer


Cosmetic Detergent Homogenizer Mixer

Product Description


Price Cosmetic Detergent Emulsifier Cream Shampoo Liquid Soap Homogenizer

Mixer Mixing Machine




Vacuum Emulsifier Introduction



Fixed-type emulsification machine is for large-volume production of products, fixed means that its lid is connected with the pot body and can not be separated. Fixed Vacuum emulsifier mainly by the pretreatment pot, the main pot, vacuum pumps, hydraulic, electrical control systems and other components. The material will be sucked into the main pot for mixing, homogeneous emulsification after been fully dissolved in Water pot and the oil pot. Its main function is the same as lift-type emulsifier with shear, emulsification function. Mainly used in biomedicine; food industry; day care products; paint inks; nano-materials; petrochemicals; dyeing auxiliaries; paper industry; pesticides and fertilizers; plastics and rubber.


Cream Shampoo Liquid Soap Homogenizer Mixer Cosmetic Detergent Emulsifier 0

Capacity Emulsify Agitator Outside Dimension total power steam/electric heating
Main Pot Water pot Oil pot KW r/min KW r/min Length Width Height
100 100 80 50 2.2-4



1.5 0-63 1800 2500 2700 8/30
200 200 160 100 2.2-5.5 2.2 0-63 2000 2750 2800 10/37
300 300 240 150 3-7.5 3 0-63 2300 2950 2900 12/40
500 500 400 250 5.5-8 3-4 0-63 2650 3150 3000 15/50
800 800 640 400 7.5-11 4-4.5 0-63 2800 3250 3150 20/65
1000 1000 800 500 7.5-11 4-7.5 0-63 2900 3400 3300 29/75
2000 2000 1600 1000 11-15 5.5-7.5 0-63 3300 3950 3600 38/92
3000 3000 2400 1500 15-18 7.5-11 0-63 3600 4300 4000 43/120

Cream Shampoo Liquid Soap Homogenizer Mixer Cosmetic Detergent Emulsifier 1


Feature of the Vacuum Emulsifier




  • The materials are sucked into emulsifying pot by transportation pipe under the vacuum state, or it also can be put from the feed inlet.
  • The material are stirred by both the center blade and side scraper, which works on the inner surface of pot keeping stirring materials from being stuck onto the wall. In the process of blade-stirring, the materials are continuously crushed, pressed, fold. Then the material is sent to the cut-off mixing unit where they are again cut off, broken and stirring by the strong interaction between running cutting wheel and cutting sheath. The materials are finally crushed into small pellets of 200um~2um. Besides, because of the vacuum in emulsifying pot, the bubbles generated during stirring and mixing process are sucked out from material. The ex-circulating system can make the homogenizing more strong. The material within the pot can be give off only under the state of change direction of the control valves.
  • The temp controller on operation panel can adjust the temp of the homogenizer pot; The homogenizer stirring and the blade stirring cab be used simultaneously or dividedly; The homogenizer stirring time can be set by the custom according to the different material. After finished the whole procession please rise the pot cover for the clearing.



Cream Shampoo Liquid Soap Homogenizer Mixer Cosmetic Detergent Emulsifier 2


tag: vacuum emulsifier, cosmetics making machine, cream lotion making equipment
