Cosmetic Cream Filling Machine/6 Filling Heads 7200 BAG cosmetic packaging equipment

Product Details:
Place of Origin: CHINA
Brand Name: QIHANG
Certification: CE, GMP, ISO
Model Number: TY
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 25424$
Packaging Details: WOODEN CASE
Delivery Time: 3-4 WEEKS
Payment Terms: L/C, D/A, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 67 SETS/YEAR

Detail Information

Number Of Filling Heads: 6 Filling Heads Production Speed: 6000-7200 Bags/hour
Bag Width: 120-170mm Length Of Bag: 140-220mm
6 Filling Mode: Gear Pump Equipment Power Supply: 220V/ 1pH
Equipment Power: 7.5KW Thermostat: Omron
Solenoid Valve: CDK Power Voltage: 380V 50HZ 6.5KW
High Light:

6 heads mask making equipment


7200B/H mask manufacturing machine

Product Description





The machine can be used for the full automation production of household and medical disposable face mask.
This is a new machine, they have to manufacture it when the order is received, delays 2 months after order and payment received.
There is a warranty of 12 months.


Adjustment of opening height

First, put the bag in the filling place. The pocket must be adjusted 2-3 millimeters higher than the suction cup, but it is at least 5 millimeters lower than the filling pipe. The guides on both sides of the bag should be 3-6 mm wider than the bag. It should not be too tight or too loose. Too tight, it is easy to clip bags, too loose, the bags are easy to clip.

Adjustment of sealing height

Adjust the height of the lower baffle by adjusting the black handle on the screw rod. The bag will rise or fall with the lower baffle to adjust the sealing height. The left black handle can adjust the width of the guide grooves on both sides of the sealing part, which should be 3-6 mm wider than the bag.

Main configuration

Kinco Touch screen
PLC Hechuan
Thermostat Omron
Electric eye Dedicated
Solenoid valve CDK
Frame Stainless steel


Input type: Thermocouple

Input Set value Range(℃) Range(℉)
K 0 -200-1300 -300-2300
1 -20.0-500.0 0.0-900.0
J 2 -100-850 -100-1500
3 -20.0-400.0 0.0-750.0
T 4 -200-400 -300-700
5 -199.9-400.0 -199.9-700.0
R 6 0-1700 0-3000
S 7 0-1700 0-3000

Default: 0


Reference temperature for general packaging materials

Packaging materials


Setting temperature


Pure aluminum/polyethylene

Cellophane/polyethylene 110~130℃
Paper/polyethylene 170~200℃
Polypropylene/polyethylene 120~140℃



Cosmetic Cream Filling Machine/6 Filling Heads 7200 BAG cosmetic packaging equipment 0Cosmetic Cream Filling Machine/6 Filling Heads 7200 BAG cosmetic packaging equipment 1Cosmetic Cream Filling Machine/6 Filling Heads 7200 BAG cosmetic packaging equipment 2



Technical Feature

1. Automatic packaging process ,No need to manual operation;
2. Material contact parts adopt high quality stainless steel manufacturing ,according to GMP standard;
3. Intelligent detection,bag filling sealing,no bag,no filling,no sealing;
4. Germany PLC system,powerful,durable;
5.The machine applies 7 inch color touch screen with easy and clear setup parameter,as well as auto diagnosis for errors;
6.Intelligent digital display temperature control system.the sealing automatic temperature compensation,temperature control
precision,the seal failure rate low.
7.The machine pneumatic selects the well-known brand,long working life,convenient maintenance replacement.
8.According to customer different way of packing,liquid injection quantity can be customized.



  • Our factory is a professional packing machine manufacturer in Jiangsu Province. We are engaged in the design, develop, manufacture, and marketing promotion of packing machines in domestic and international markets.

  • We offer a full range of packing machines which include emulsifying mixer, planetary mixer, tube filling and sealing machine, adhesive filling and capping machine, and box packing machine,overwrapping machine.

  • Our machines are widely used in daily cosmetic,chemicals, pharmacy, medicines, adhesives and food industries.
