China Cosmetic Making Machine manufacturer

cosmetic cream making machine 63r Mn Vacuum Homogenizer Supplier 0.2 Um Perfume Making Equipment Sales

Product Details:
Place of Origin: China
Brand Name: Qihang
Certification: CE
Model Number: CV1
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 5414$-6547$
Packaging Details: According to product
Delivery Time: 2-3 weeks
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 87 SETS/YEAR

Detail Information

Voltage: 220V/380V 50HZ Mixer Type: Homogenizer
Product Name: Cosmetic Making Machine Mixing Speed: 0-63 R/min Or Custom
Product Type: Cosmetic Automatic Grade: Automatic
Advantage: Defoaming And Longer Shelf Life Condition: New
High Light:

cosmetic processing equipment

,

emulsion mixer machine

Product Description

cosmetic cream making machine 63r Mn Vacuum Homogenizer Supplier 0.2 Um Perfume Making Equipment Sales

Shaving Face Skin Body Cosmetic Cream Making Machine with Mixer Homogenizer



cosmetic cream making machine	63r Mn Vacuum Homogenizer Supplier  0.2 Um Perfume Making Equipment Sales 0



Introduction of the Vacuum Homogenizer:

The designing of Vacuum Emulsifying Mixer is based on importing advanced technology of professional cosmetic and pharmaceutical ointment producing workmanship from abroad. It is composed of emulsifying mixer, vacuum system, electric controlsystem etc. The whole-set of this equipment is composed of emulsifying mixing pot, Vacuum system, Hydraulic system, and electrical controlsystem.



Technical data of the Vacuum Homogenizer:

Model Mixing power Volume Revolution Mixing speed Dispersing power Dispersing speed
CV-2 0.55kW 2L 0-65r/min 0-105r/min 0.75kW



0-2880r/min



CV-5 0.75kW 5L 0-65r/min 0-105r/min 1.1kW
CV-15 1.5kW 15L 0-60r/min 0-95r/min 1.5kW
CV20 2.2kW 20L 0-60r/min 0-95r/min 2.2kW
CV-30 3.0kW 35L 0-50r/min 0-80r/min 3.0kW
CV-50 4.0kW 50L 0-50r/min 0-80r/min 5.5kW
CV-100 5.5kW 100L 0-60r/min 0-90r/min 11kW
CV150 11kW 150L 0-50r/min 0-80r/min 18.5kW



0-1440r/min

CV-200 15kW 200L 0-50r/min 0-80r/min 22kW
CV-300 18.5kW 350L 0-30r/min 0-65r/min 22kW
CV-500 30kW 500L 0-30r/min 0-50r/min 37kW



0-1000r/min

CV-700 37kW 700L 0-30r/min 0-50r/min 45kW
CV-1000 45kW 1000L 0-30r/min 20-45r/min 55kW
CV-1500 55kW 1500L 0-25r/min 20-40r/min 90kW



Description Details
Name Vacuum Emulsifier Mixer



Advantage

Make production under vacuum → De-foaming
Vacuum to suck raw material → Anti-bacteria
Lid with hydraulic lifting system→ Easy cleaning + Tilting discharge



Applications

1. Food: mayonnaise, tomato paste, cake gel, honey, chocolate etc.
2. Medical: ultrasound gel, injection, syrup, etc.
3. Cosmetic: cream, body lotion, shaving foam, toothpaste, etc.



Application of the Vacuum Homogenizer:

The Vacuum Emulsifying Mixer is composed of main pot(emulsifying pot),a water phase pot and an oil phase pot, vacuum unit, up-and down system, electrical control system and the motor frame etc.

cosmetic cream making machine	63r Mn Vacuum Homogenizer Supplier  0.2 Um Perfume Making Equipment Sales 1

GPM planetary mixer:

GPM planetary mixer usually contains two agitators: wall scraper mixing and high speed mixing. The wall scraper mixing can be frame or anchor type with scrapers. It rotates to mix materials and to scrape materials attached on the container wall at the same time. High speed mixing ensures to mix and disperse materials quickly and efficiently. No dead corners and residuals. Easy to clean and ensure mixture efficiency.



Features of the Vacuum Homogenizer:

1. Integrate mixture, dispersion and wall scraper in one machine

2. Mechanical seal, O ring seal or trapezoid seal for option material reaction can happen under vacuum condition

3. High and low speed impellers rotate rapidly and exert strong impact force to mix materials thoroughly in a very short time. No deposit and residuals

4. Inverter control, various speed adjustment

5. Mirror polishing to ensure its smoothness

6. Suitable for liquid-liquid mixing, solid-liquid mixing, paste-paste mixing, powder-paste mixing in adhesives, lithium battery and cosmetics production. Maximum viscosity can reach 2000000cps.

cosmetic cream making machine	63r Mn Vacuum Homogenizer Supplier  0.2 Um Perfume Making Equipment Sales 2

  • Frame mixer

Dead-end stirring with sufficient mixing area and good stirring effect.

  • High shear homogenizer

Fast agitator: teethed type rotor and stater assembly installed on the vessel. Bottom or on the top as optional items, several interchangeable configurations ate available.

  • Hydraulic lifting system

Used for material discharge and cleaning. It is more convenient and safer for the operator.

  • Pharmaceutical grade material

High quality SUS304 & 316 material, internal and external mirror polish of homogenized tank.



Function selection:

1. With jacket or coiler-pipe for heating/cooling

2. With temperature detector for control and data acquisition

3. Configured with extruder for option

4. Configured with PLC automatic control system with human-computer interface for option

5. Various agitators for option to satisfy different production requirements



Project Cases:

Manage ltem: vacuum homogenizing emulsifiers, high shear liquid detergent mixers, reverse osmosis ion water devices, various water injection, liquid and ointment semi-automatic and automatic filling production lines, round and flat bottles automatic and semi-automatic labeling machines, perfume whole-set production lines, laboratory equipment, flow lines, etc.



Customer Reviews:

cosmetic cream making machine	63r Mn Vacuum Homogenizer Supplier  0.2 Um Perfume Making Equipment Sales 3
